V2 ATRIS 1000 Garage Door Motor Head Unit

Extra Specification & Feature Information

The V2 ATRIS 1000 N is a robust and reliable electromechanical irreversible actuator designed for sectional and counterbalanced garage doors. Delivering a maximum thrust of 1000 N and suitable for door areas up to 10 m², it combines power, safety, and flexibility to handle everyday use with ease.

Key Features

• Accurate and safe operation – encoder ensures precise movement and safety
• Obstacle detection for enhanced protection
• Fast operation mode available on the ATRIS-1000 version
• Self-learning of times, slow-downs, and forces for smooth operation
• Integrated sound signalling during automatic closing
• Optional battery backup (B-PACK) for operation during power cuts
• Optional solar power via the ECO-LOGIC system
• Simple programming via keypad and LCD display with quick menu
• Plug-in slot for MR2 modular radio receiver
• Inputs for photocells, safety edges, external start/stop buttons
• Output for 24V flashing light with intermittence

Technical Specifications

• Power Supply: 230V ~ 50 Hz
• Maximum Power: 330 W
• Standby Consumption: <0.5 W
• Door Area: up to 10 m²
• Start Force: 700 N
• Maximum Speed: 12 cm/s (opening) – 14 cm/s (closing)
• Working Temperature: –20°C to +40°C
• Duty Cycle: 30%
• Protection Rating: IP20
• Weight: 6 kg

Why Choose the V2 ATRIS?

Combining Italian engineering with flexible features, the V2 ATRIS is ideal for modern homes and commercial premises needing a balance of performance and safety. With options for solar integration, battery backup, and advanced control functions, it delivers reliability, energy efficiency, and peace of mind.
