V2 FOT180BAT Wireless photocell beam with battery – rotation up 180° for low voltage and inverter systems

Extra Specification & Feature Information

Synchronized, adjustable (180°), wall mounted photocells with battery powered transmitter. For 24Vdc and 230V automation with inverter
• Possibility to connect a resistive or traditional safety edge on the transmitter
• Synchronised: ability to set two different transmission codes to simultaneously use two pairs of  photocells without mutual interference
• Adjustable up to 180° on the horizontal axis and 30° on the vertical axis
• Automatic slow down of the detection signal in the event of snow to avoid undesired activations caused by the fall of the flakes
• Possibility to connect a resistive or traditional safety edge on the transmitter
• Synchronised: ability to set two different transmission codes to simultaneously use two pairs of photocells without mutual interference
• Adjustable up to 180° on the horizontal axis and 30° on the vertical axis
• Possibility to adjust the intervention speed

Optical range (m) 20
Dimensions (mm) 40 x 104 x 36
Power supply (RX) 12÷24 Vac
Power supply (TX) 2 batteries 1,5V AAA
Relay contact (A) max 500mA e 48 Vac
Working temperature (°C) -20 ÷ +55
Protection degree (IP) 55
